THK SHS65V Original THK Linear Bearing Block
- Easy maintenance
- Improved productivity of the machine
- Substantial energy savings
- Low total cost
- Higher accuracy of the machine
- Higher efficiency in machine design
- Original THK Products
- Delivery on 3 days
THK SHS65V Product Specifications
| Parameter | Value |
|---|---|
| Brand | THK |
| Model No. | SHS65V |
| Outer Dimensions Height M | 90 mm (3.543 in) |
| Outer Dimensions Width W | 126 mm (4.961 in) |
| Outer Dimensions Length L | 221 mm (8.701 in) |
| LM Block Dimensions B | 76 mm (2.992 in) |
| LM Block Dimensions C | 70 mm (2.756 in) |
| Mounting Hole (S×ℓ) | M16×20 |
| L1 | 175 mm (6.890 in) |
| T | 19.5 mm (0.768 in) |
| K | 71 mm (2.795 in) |
| N | 19 mm (0.748 in) |
| E | 16 mm (0.630 in) |
| Grease Nipple | B-PT1/8 |
| e0 | 10 mm (0.394 in) |
| f0 | 12 mm (0.472 in) |
| D0 | 5.2 mm (0.205 in) |
| LM Rail Dimensions Width W10-0.05 | 63 mm (2.480 in) |
| LM Rail Dimensions W2 | 31.5 mm (1.240 in) |
| LM Rail Dimensions Height M1 | 53 mm (2.087 in) |
| LM Rail Dimensions Pitch F | 150 mm (5.906 in) |
| LM Rail Dimensions d1×d2×h | 18×26×22 |
| LM Rail Standard Lengths (G, g) | 3000 (35, 115), 5000 (35, 15) mm |
| LM Rail Maximum Length | 7000 mm (275.591 in) |
| Basic Dynamic Load Rating C | 205 kN (46085.9 lbf) |
| Basic Static Load Rating C0 | 320 kN (71938.9 lbf) |
| Static Permissible Moment MA1 (Single Block) | 8.26 kN-m (73.1 lbf-in) |
| Static Permissible Moment MA2 (Double Blocks) | 40.4 kN-m (357.6 lbf-in) |
| Static Permissible Moment MB1 (Single Block) | 8.26 kN-m (73.1 lbf-in) |
| Static Permissible Moment MB2 (Double Blocks) | 40.4 kN-m (357.6 lbf-in) |
| Static Permissible Moment MC1 (Single Block) | 9.4 kN-m (83.2 lbf-in) |
| LM Block Mass | 8.41 kg (18.54 lbs) |
| LM Rail Mass | 23.7 kg/m (15.93 lbs/ft) |
